Description

ASUS nVidia GeForce ROG-ASTRAL-LC-RTX5090-O32G-GAMING 32GB GDDR7 2580 MHz Boost clock 28 Gbps 512-bit Digital Max Resolution 7680 x 4320

Graphic Engine
NVIDIA® GeForce RTX™ 5090
AI Performance
3593 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
32GB GDDR7
Engine Clock
OC mode: 2610 MHz
Default mode: 2580 MHz(Boost clock)
CUDA Core
21760
Memory Speed
28 Gbps
Memory Interface
512-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 2 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1b)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Speedsetup Manual
1 x ROG Graphics Card Holder
1 x ROG Velcro Hook & Loop
1 x ROG Magnet
1 x ROG PCB Ruler
1 x Thank You Card
1 x Adapter Cable (1 to 4)​
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
Card 288.46 x 153.7 x 48 mm
Radiator: 400 x 120 x 65mm
Recommended PSU
1000W
Power Connectors
1 x 16-pin
Slot
2.5 Slot
AURA SYNC
ARGB

ROG Astral LC GeForce RTX™ 5090 32GB GDDR7 OC Edition

ROG Astral LC GeForce RTX™ 5090 32GB GDDR7 OC Edition – Experience Fluid Force with a 360 mm AIO cooler for optimal performance that can achieve the highest GPU boost clock
AI Performance: 3593 AI TOPS
Powered by the NVIDIA Blackwell architecture and DLSS 4
OC mode: 2610 MHz (OC mode)/ 2580 MHz (Default mode)
360mm radiator balances compatibility and performance
Magnetic daisy-chainable fans make installation and cable management easier
Full-coverage cold plate brings liquid cooling to GPU die, VRMs and memory
Phase-change GPU thermal pad helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
On-board cooling is handled by an axial-tech fan and low-profile heatsink
Powerful 80-amp MOSFETs help ensure enhanced performance, stability and higher overclocking potential
Secure GPU protection with GPU Guard technology securing four corners of the GPU and GPU bracket ensures stable mounting
Protective PCB coating guards against moisture, dust, and extreme temperatures
Auto-Extreme manufacturing process helps ensure precision and reliability
GPU Tweak III software provides intuitive performance tuning, advanced thermal controls and system monitoring
